System Introduction

We offer highly customized solutions based on the specific on-site conditions of the client, achieving comprehensive and full-function monitoring. We emphasize system data integration and information sharing to improve the overall operational efficiency of the enterprise. In system design, we prioritize stability and reliability, incorporating redundancy and VMware backup rules for continued operation and recovery. We also ensure robust system scalability to easily meet the client's expansion needs.

The computer configuration table contains information such as the number, location, and software of virtual machines and physical machines.

*The IP master list includes computers, PLCs, hubs, communication equipment (Modbus), etc.

*The shared control program includes graphical control and PLC.

*The rack location diagram shows the installation locations of the production racks and network racks.

The delivery equipment list includes the specifications, quantity, and delivery date of the relevant FMCS hardware.

The personnel lists for each system include information on users, groups, computers, files, printers, etc.

Sample report files (daily, weekly, monthly).

*When collecting data from P&ID diagrams or graphical control screens of various systems, IO addresses must also be provided.

FMCS System 20% Progress Report

Is the image control function working properly

*Are the PLC communication and I/O functions working properly

*Does the PLC use shared programs

*The PLC outputs the IO list.

Alarm thresholds and alarm annotations for each system.
